VAN ĐIỀU ÁP THẤP ÁP REGO LV4404B4

Hãng sản xuất:

REGO

Mã sản phẩm:

LV4403B4

VAN ĐIỀU ÁP CẤP HAI REG0 LV4403B4
Model: LV4403B4, LV4403B46, LV4403B46R, LV4403B66, LV4403B66R
Xuất xứ: Rego USA

Designed to reduce first stage pressure of 5 to 20 PSIG down to burner pressure, normally 11” w.c. Ideal for medium commercial installations, multiple cylinder installations and normal domestic loads

LH: 0901268208

Low Pressure Second Stage Regulators - Standard Settings LV4403B Series

Application Designed to reduce first stage pressure of 5 to 20 PSIG down to burner pressure, normally 11” w.c. Ideal for medium commercial installations, multiple cylinder installations and normal domestic loads.

Features • Large vent helps prevent blockage and has ¾" F.NPT for vent piping. • With 15 PSIG inlet pressure, regulator is designed to not pass more than 2 PSIG with the seat disc removed. • Incorporates integral relief valves. • Replaceable valve orifice and valve seat disc. • Straight line valve closure reduces wear on seat disc. • Unique bonnet vent profile minimizes vent freeze over when properly installed. • Large molded diaphragm is extra sensitive to pressure changes. • Built in pressure tap has plugged ⅛ F.NPT outlet. Plug can be removed with a 3⁄16" hex allen wrench. • Select brown finish.

van dieu ap LV4403B4
