High Pressure First Stage Regulators LV4403SR and TR Series

Hãng sản xuất:

REGO

Mã sản phẩm:

LV4403TR9

VAN ĐIỀU ÁP REGO LV4403SR
Model: LV4403SR4, LV4403TR4, LV4403SR9, LV4403TR9, LV4403SR96, LV4403TR96
Xuất xứ: Rego USA

Provides accurate first stage regulation in two-stage bulk tank systems. Reduce tank pressure to an intermediate pressure of 5 to 10 PSIG. Also used to supply high pressure burners for applications like industrial furnaces or boilers. Also incorporated in multiple cylinder installations.

LH: 0901268208

High Pressure First Stage Regulators LV4403SR and TR Series

Application
Provides accurate first stage regulation in two-stage bulk tank systems. Reduce tank pressure to an intermediate pressure of 5 to 10 PSIG. Also used to supply high pressure burners for applications like industrial furnaces or boilers. Also incorporated in multiple cylinder installations.
Features
Incorporate integral relief valves for added system protection. • Large vent helps prevent blockage and has ¾” F.NPT thread for vent piping. • Bonnet vent positioned over outlet to avoid icing and contamination by foreign material. • Unique bonnet vent profile designed to minimize vent freeze over when properly installed. • Replaceable valve orifice and valve seat disc. • Straight-line valve closure reduces wear on seat disc. • Large molded diaphragm is extra sensitive to pressure changes. • Built in pressure tap has plugged ⅛” F.NPT outlet. • Plug can be removed with a 3⁄16” hex allen wrench. • Extra long lever arm provides uniform delivery pressure. • Brilliant red finish
